National Material Handling delivers both standard and custom-engineered solutions to resolve pallet rack upright damage — a common challenge even in the most well-run facilities. Our rack repair systems help you maintain a safer work environment, extend the life of your storage systems, and minimize costly downtime. Contact our U.S. warehouse solutions team to learn more.
Rack Repair Options
- Centurion – Low Guard
- Centurion – Mid guard
- Centurion – High Guard
- Centurion – Row Guard
- Centurion Vanguard
Rack Repair Sizes
- Centurion – Low Guard: Dedicated to the bottom 16″ of the and made to fit 3″,4″ or 5″ uprights. Most cost effective heavy-duty solution for damage to the bottom of the upright or at the base plate.
- Centurion – Mid Guard: Repairs damage up to 48″ of the upright and made to fit 3″, 4″ or 5″ uprights. Choose from teardrop and structural hole patterns.
- Centurion – High Guard: An extension that’s added to the Mid Guard to repair damage up to 13′ and made to fit 3″, 4″, or 5″ uprights
- Centurion – Row Guard: Preventative solution protecting your rack against side impacts it guards and repairs both front and rear uprights. The Row Guard comes in heights of: 24″- 38″ and depths of: 36″ – 48″.
- Centurion Vanguard: Available for additional durability or replacement of a double reinforced column and made to fit 3″, 4″ or 5″ uprights. The VanGuard increases impact resistance of racking ranging from 24″ to 83″ in height.
Rack Repair Features
- Telescoping Adjustable horizontal & Diagonal Bracing
- In line or Seismic Base plate options
- Adjustable Saddle Bracing
- Beam Dodger Options
Low Guard:
- ¾” x 5 ½” Wedge Anchors
- Grade 5 Carriage Bolts
- “No Snag” Side Connections
- ½” Thick Base
- Gusset for Added Strength
Mid Guard, High Guard:
- ¾” x 5 ½” Wedge Anchors
- Grade 5 Carriage Bolts
- “No Snag” Side Connections
- ½” Thick Base
Row Guard:
- ¾” x 5 ½” wedge anchors
- Grade 5 carriage bolts
- ½” thick base
Pallet Rack Repair Benefits
-
Less Warehouse Downtime
Pallet rack repair solutions can be installed in 30-45 minutes. They don’t require you to off-load the rack like you would have to do if you were replacing the pallet rack upright entirely. Rack repair solutions are in stock and ready to ship from our suppliers.
-
Improve Warehouse Safety
Our team of experts can perform routine pallet rack inspections and keep your rack safe by enhancing the structural integrity of your pallet rack uprights.
-
Reduced Lead Times & Shipping Costs
Most of our repair solutions are available in quick-ship and ship LTL on a 42”x48” pallet.
-
Factory Certified Installation Crew
When our certified installers are used, rack repair kits come with a manufacturer-supported warranty.
Below is information that will help National Material Handling provide you with an accurate quote for .
Job Site Information
- Location: City and state
- Facility use: (e.g., distribution, manufacturing, cold storage, etc.)
- Operating hours: Days and times when our team can safely access the area
Type of Racking
- Selective
- Drive-In / Drive-Through
- Push-Back
- Cantilever
- Other (please specify)
Rack Construction
- Structural Steel
- Roll-Formed Steel
Damage Details
- Height of damage
- Column Size (Width) and Style
- Number of Beam Levels affected
- Photos (If Available)
Pallet Rack Repair Pricing
Pallet Rack Repair FAQ
-
How Do I Determine What Type of Repair Solution I Need?
The rack repair kit needed is determined based on the highest point of damage with beam levels being taken into consideration. Repair solutions range from our Centurion Low-Guard dedicated to the bottom 13″ and all the way up to 13′ when our Centurion High Guard is installed. Custom options are available upon request.
-
How Do I Determine What Size Repair Solution I Need?
The repair solution size is based on the highest point of damage with beam levels being taken into consideration. Repair solutions are sized in 12” increments starting at 24” and going to 96” in standard solutions. Custom repair options available upon request.
-
Why Use a Repair Solutions Instead of Replacing a Damaged Upright?
While every instance of rack damage is different, pallet rack repair kits are typically the most economical and practical choice. They’re engineered for strength, install quickly with minimal disruption, and permanently reinforce the damaged area. Unlike full upright replacements, a repair kit enhances impact resistance — keeping your rack system safer for years to come.
Request a Quote for Pallet Rack Repair
National Material Handling is proud to serve as your trusted US warehouse solutions company. Submit an RFQ today to learn more about our pallet rack repair services. Call National Material Handling at (317) 886-0660 or fill out our online contact form to get started.
